01 / JUNWEI
Dedicated Wire Mesh Welding
Dedicated equipment for mesh panels and wire assemblies. Discuss the welding layout, fixture and workpiece movement.
Dedicated mesh welder
Wire mesh welding machines
A Welding Layout
Built Around Your Mesh.
Bring your wire pattern, weld positions and production requirements to JUNWEI. Explore dedicated mesh welding, row welding and rack-welding equipment with tooling arranged for your workpiece.
- Equipment for mesh panels and wire products
- Fixture and electrode arrangements to discuss
- Loading and workpiece-positioning requirements
- Dedicated automation options for your production
- Brand
- JUNWEI
- Product family
- Wire mesh & row welding
- Applications
- Mesh panels, racks, grills and wire assemblies
- Configuration
- Selected for the part and welding layout
Share your material, workpiece dimensions and production requirements.
EXPLORE THE SERIES
Equipment for Different Wire Products
Start with the workpiece to discuss the machine arrangement.
02 / JUNWEI
Row Welding Equipment
Explore row welding arrangements for racks, grills and wire products. Share the weld positions and part access requirements.
03 / JUNWEI
Rack & Grate Welding
Discuss a setup around your rack or grate, including part support, electrode access and the loading workflow.
FIXTURES & WELDING ACCESS
The Details Start with Your Drawing
Close-up views from the original supplier product photographs.
Workpiece support & positioning
Share the overall panel dimensions, wire spacing and loading method to discuss a fixture that supports your part.
Electrode & tooling arrangement
Share the weld positions and access requirements so the tooling layout can be reviewed for your wire product.
APPLICATION DISCUSSIONS
What Do You Need to Weld?
Mesh panels
Wire diameter, mesh spacing, panel dimensions and the sequence of weld positions.
Racks & grills
Part outline, intersecting wires, support points and electrode access.
Wire assemblies
Formed-wire geometry, joining points, fixtures and the required loading workflow.
MACHINE CONFIGURATION
From Wire Pattern
to Welding Setup.
Prepare a drawing or sample information for the mesh or rack you produce. Welding capacity, electrode layout, working dimensions and cycle requirements need to be confirmed for the selected machine.
| Wire material | Material grade, surface condition and coating |
|---|---|
| Wire dimensions | Diameter of each wire and any differences between directions |
| Mesh pattern | Grid spacing, overall dimensions and weld positions |
| Fixtures & loading | Part support, positioning and operator workflow |
| Production needs | Target output, product changes and automation requirements |
| Acceptance criteria | Weld quality, inspection and sample requirements |
INSIDE JUNWEI
From Machine Design to Assembly
LET’S TALK ABOUT YOUR WIRE PRODUCT
Share Your Mesh or Rack Drawing.
Tell us about the wire, weld positions and production requirements.
