Air-conditioner component welding
From the Base Plate
to the Welding Setup.
Explore JUNWEI equipment for air-conditioning base assemblies. Share the stamped-part drawing, attachment positions and production requirements to discuss fixtures, welding access and the operating sequence.
- Dedicated equipment shown in the JUNWEI air-conditioning series
- Base-plate and attached-component applications
- Automatic and semi-automatic options to discuss
- Positioning and tooling planned around your assembly
- Brand
- JUNWEI
- Product family
- Air-conditioning component welding
- Workpiece
- Base plates and component assemblies
- Configuration
- Confirmed against your part drawing
Share your material, workpiece dimensions and production requirements.
START WITH THE ASSEMBLY
Base Plates, Supports & Joining Positions
Component examples from the original supplier artwork. Use your drawing to define the required joints.
Stamped base components
Share the base outline, formed features and accessible positioning surfaces.
Base & support assemblies
Show the attachment locations, component dimensions and required joint layout.
EQUIPMENT LAYOUTS
Plan Access Around the Workpiece
Two equipment examples appear in the air-conditioning series. Select the arrangement for your part and workflow.
Extended workpiece support
Discuss loading access, support for the base plate and positioning at the welding area.
Multiple welding heads
Review the weld locations, tooling access and operating sequence required by your assembly.
Equipment and component views are crops of the same original series artwork.
PLAN THE PRODUCTION WORKFLOW
Locate the Base. Position the Parts. Define the Sequence.
- 01
Locate the base plate
Identify reference holes, formed edges and support points for repeatable part positioning.
- 02
Position the components
Share each attachment position and the clearance available for fixtures and welding tooling.
- 03
Choose the workflow
Discuss automatic or semi-automatic operation, loading, unloading and inspection requirements.
MACHINE CONFIGURATION
Share the Assembly.
Specify the Production Needs.
Prepare the component drawings and weld requirements before equipment selection. Working dimensions, weld capacity, fixture layout and production output must be confirmed for the proposed setup.
| Base plate | Material, thickness, dimensions and formed features |
|---|---|
| Attached parts | Component drawings, contact surfaces and assembly positions |
| Joint layout | Weld locations, spacing and tooling clearance |
| Fixturing | Reference points, support, clamping and loading access |
| Production needs | Target output, product variants and intended automation |
| Acceptance criteria | Weld quality, dimensional checks and inspection requirements |
